Motherboard configuration | EATX (Max. 12" x 13") SSI EEB 3.0 |
Processor | Intel / AMD DP Quad |
Security | Intrusion Switch, Keylock on front door |
Drive configuration | - 3 x 5.25"
- 1 x 3.5" FDD
- 4 x 3.5" HDD
- 1 x Slim 5.25"
|
Metal Material | SGCC |
Plastic Material Type | ABS-HB |
Metal Thickness | 1.2mm |
System cooling fans | 1 x 12mm PWM, 2 x 80mm (Option) |
Expansion Slot | 7 or 15 Full Height |
Front Panel | Power On/Off, System Reset, Power LED, 1 x HDD Activity, 2 x LAN Activity LED, 2 x USB 2.0 |
Net Weight/Gross Weight | 12.5kg/15.5kg |
Optional Power Supply | 400W-700W (PS/2 Size Single up to 700W) or MRW-5450V (Mini Redundant PSU up to 500W) (Rear Installation), Max. Depth 300mm |
Optional Kits | SK33502 (3 x ODD bays to 5 x 3.5" hot-swap HDD bays), 22" Sliding Rail, 80mm fans,15 slot rear windows, Foot Stand |
