RM413 Chenbro 4U High Performance

Features:

  • Chenbro 4U High Performance Industrial Server Chassis
  • Truly isolation anti-vibration design on internal HDD and drive cages
  • Card retainer to hold LP and full height add-on cards
  • Support stand-alone installation via optional kit

Description

Specifications:

Case dimension430mm W x 546mm D x 176mm H
Motherboard configurationEATX (Max. 12" x 13") SSI EEB 3.0
ProcessorIntel / AMD DP Quad
SecurityIntrusion Switch, Keylock on front door
Drive configuration
  • 3 x 5.25"

  • 1 x 3.5" FDD

  • 4 x 3.5" HDD

  • 1 x Slim 5.25"

Metal MaterialSGCC
Plastic Material TypeABS-HB
Metal Thickness1.2mm
System cooling fans1 x 12mm PWM, 2 x 80mm (Option)
Expansion Slot7 or 15 Full Height
Front PanelPower On/Off, System Reset, Power LED, 1 x HDD Activity, 2 x LAN Activity LED, 2 x USB 2.0
Net Weight/Gross Weight12.5kg/15.5kg
Optional Power Supply400W-700W (PS/2 Size Single up to 700W) or MRW-5450V (Mini Redundant PSU up to 500W) (Rear Installation), Max. Depth 300mm
Optional KitsSK33502 (3 x ODD bays to 5 x 3.5" hot-swap HDD bays), 22" Sliding Rail80mm fans,15 slot rear windowsFoot Stand
